VALANT SBRTU

Look at picture of card.

The small-sized VALANT™ Single-board RTU provides advanced telemetry and control functions for SCADA (Supervisory, Control, and Data Acquisition) systems.

Status changes on the eight digital inputs are automatically tallied to separate 16-bit registers which allow these inputs to provide interscan change counts or function as low speed pulse accumulators. The unit's firmware is tailored by ADC per requirements to provide protocol support and other real-time routines for process automation. Configuration data is stored in a non-volatile EEPROM memory.

Two ports are available for dedicated communications to a host station computer, a Master Station, and/or dial-up computer. The unit's data can also be accessed on-site with a portable personal computer.

Input/Output: 8DI 8AI 6DO

Input/Output: 16DI 16AI 12DO (with expansion card)

__________________________________________

APPLICATIONS

• Electric power distribution
• Oil and Gas pipeline control
• W / WW lift station control
• Automated terminals and tank farms
• Transportation signals

__________________________________________

FEATURES

• Multiple protocol support
• Firmware upward compatible
• CMOS circuitry for minimum power consumption and high noise immunity
• Reprogrammable, non-volatile EEPROM retains configuration data during loss of power
• Industrial quality components and workmanship for long and reliable operation

____________________________________________________________________________________________

SPECIFICATIONS

__________________________________________

Operating environment (electronics)

• Standard -10 to +70°C temperature
• 0 to 95% relative humidity (non-condensing)

__________________________________________

Operating power

• 10-14VDC input power
  (AC/DC-DC converters/chargers available)
• Typical logic current drain 150mA

__________________________________________

Digital inputs ("status"), isolated

• Signal must sink 5mA from 12VDC source
• Optical coupler input with 5000V isolation

__________________________________________

Analog inputs (A/D conversion)

• Conversion accuracy: ±0.10% of span
• Conversion resolution: 1 part in 2000
• Common mode rejection: >80dB @ 60Hz,
  60dB @ DC
• Common mode input range: ±36V
• Accepts ±1mA, ±5V (bipolar) signals or 420mA, 0-5V (unipolar) signals

__________________________________________

Optional (soft) pulse inputs

• Input frequency: DC to 13Hz

__________________________________________

Transient protection

• Meets or exceeds IEEE C37.90A-1987
  surge withstanding specification

__________________________________________

Primary control outputs

• Open collectors (sinks 100mA @ 28VDC) formed by fail-safe/redundant circuitry
• Optional interposing relays per requirements

__________________________________________

Dual communication ports

• Each port independently configurable for channel (RS232, RS422, RS485), data rate, and protocol (async/sync)

__________________________________________

ADDITIONAL INFORMATION

Push the "BACK" button in your browser program after viewing the following pages, to return to this page:

Look at picture of card.

__________________________________________

ORDERING INFORMATION

200084: VALANT RTU CARD

200084-002 $927

Specify communications protocol and/or firmware version when ordering.

OPTIONAL EXPANSION BOARD. Adds 8DI, 8AI, and 6DO to the base board functionality.

200086-000 $707

OPTIONAL LINE DRIVER CHIPS. These components replace the standard RS-232 line driver I.C. (socketed DIP).

200127-001, RS-485 $24

200127-002, RS-422 $24
